2024 CHEVROLET SILVERADO 2500HD & 3500HD SPECIFICATIONS (Click to expand)
CONFIGURATIONS
2500HD
|
Regular Cab Long Bed (2WD & 4WD)
Double Cab Standard Bed (2WD & 4WD)
Double Cab Long Bed (2WD & 4WD)
Crew Cab Standard Bed (2WD & 4WD)
Crew Cab Long Bed (2WD & 4WD)
|
3500HD
|
Regular Cab Long Bed (2WD & 4WD) – single rear wheels
Regular Cab Long Bed (2WD & 4WD) – dual rear wheels
Double Cab Long Bed (2WD & 4WD) – single rear wheels
Double Cab Long Bed (2WD & 4WD) – dual rear wheels
Crew Cab Standard Bed (2WD & 4WD) – single rear wheels
Crew Cab Long Bed (2WD & 4WD) – single rear wheels
Crew Cab Long Bed (2WD & 4WD) – dual rear wheels
|
ENGINES
Type:
|
6.6L V-8 gasoline or E85 FlexFuel
|
Bore & Stroke (in / mm):
|
4.06 x 3.86 / 103.25 x 98
|
Block Material:
|
Cast iron with nodular iron main caps
|
Cylinder Head Material:
|
Cast aluminum
|
Compression Ratio:
|
10.8:1
|
Valvetrain:
|
Overhead-valve, two valves per cylinder, variable valve timing
|
Fuel Delivery:
|
Direct fuel injection
|
Horsepower
(hp / kW @ rpm):
|
401 / 299 @ 5200 (SAE certified – gasoline)
|
Torque
(lb.-ft. / Nm @ rpm):
|
464 / 629 @ 4000 (SAE certified – gasoline)
|
Type:
|
Duramax 6.6L V-8 Turbo-Diesel
|
Bore & Stroke (in / mm):
|
4.05 x 3.89 / 103 x 99
|
Block Material:
|
Cast iron
|
Cylinder Head Material:
|
Cast aluminum
|
Compression Ratio:
|
16.0:1
|
Valvetrain:
|
Overhead-valve, four valves per cylinder
|
Fuel Delivery:
|
Common-rail direct fuel injection
|
Horsepower
(hp / kW @ rpm):
|
470 / 350 @ 2800 (Per SAE J1349)
|
Torque
(lb.-ft. / Nm @ rpm):
|
975 / 1322 @ 1600 (Per SAE J1349)
|
TRANSMISSION & AXLE
Type:
|
Allison® 10L1000 10-speed automatic
|
Gear Ratios (:1):
|
|
First
|
4.54
|
Second
|
2.87
|
Third
|
2.06
|
Fourth
|
1.72
|
Fifth
|
1.48
|
Sixth
|
1.26
|
Seventh
|
1.00
|
Eighth
|
0.85
|
Ninth
|
0.69
|
Tenth
|
0.63
|
Reverse
|
4.54
|
Final Drive Ratio:
|
3.73 (6.6L gas)
3.42 (6.6L diesel)
|
CHASSIS & SUSPENSION
Front Suspension:
|
Short long arms independent front suspension with torsion bars
|
Rear Suspension:
|
Semi-elliptic three-stage multi-leaf springs (3500-series leaf springs and shocks included on 2500 with available Max Towing package)
|
Steering Type:
|
Hydraulic power-assisted recirculating ball; includes Digital Variable Steering Assist on LTZ and High Country
|
Brake Type:
|
Hydraulic power-assisted Hydroboost brake booster, four-wheel disc brakes with ABS and Stabilitrak electronic stability assist
|
Brake Rotor Size (in / mm):
|
Front: 14 x 1.6 / 355 x 40 (2500/3500)
Rear: 14.1 x 1.3 / 360 x 34 (2500/3500 SRW)
Rear: 14 x 1.6 / 355 x40 (3500 DRW)
|
Wheel Size:
|
17-in. steel (2500 and 3500 w/DRW)
17-in. aluminum (2500)
18-in. steel or aluminum (2500 and 3500)
20-in. aluminum (2500 and 3500)
|
Tire Size:
|
LT235/80R17 ALS and AT (3500HD DRW)
LT265/70R17 AT
LT245/75R17 ALS
LT275/70R18 AT
LT275/65R20 AT
|
FUEL TANK CAPACITY (approx.)
|
Regular Cab
|
Double Cab
|
Crew Cab
|
Fuel Tank (gal. / L):
|
36 / 136 – gas
28 / 106 – diesel
|
36 / 136 – gas
29.4 / 111 – diesel (standard bed)
36 / 136 – diesel (long bed)
|
36 / 136 – gas
36 / 136 – diesel
|
EXTERIOR DIMENSIONS
|
Regular Cab
|
Double Cab
|
Crew Cab
|
Wheelbase
(in. / mm):
|
141.55 / 3595 (long bed)
|
149.4 / 3795 (standard bed)
162.48 / 4127 (long bed)
|
158.94 / 4037 (standard bed)
172 / 4369
(long bed)
|
Overall Length
(in. / mm):
|
235.5 / 5982 (long bed)
|
240.45 / 6107 (standard bed)
256.46 / 6514 (long bed)
|
249.95 / 6349 (standard bed)
266 / 6759
(long bed)
|
Overall Width (in. / mm):
|
81.75 / 2076 (SRW)
96.75 / 2457 (DRW)
|
81.85 / 2079 (SRW)
96.75 / 2457 (DRW)
|
81.85 / 2079 (SRW)
96.75 / 2457 (DRW)
|
Overall Height
(in. / mm):
|
79.94 / 2030 (2500HD)
80.94 / 2056 (3500HD SRW)
80.24 / 2038 (3500HD DRW)
|
79.95 / 2031
(2500HD std. bed)
79.8 / 2027
(2500HD long bed)
80.87 / 2054
(3500HD SRW)
80.2 / 2037
(3500HD DRW)
|
79.82 / 2027 (2500HD std. bed)
79.65 / 2023 (2500HD long bed)
80.87 / 2054 (3500HD std. bed)
80.67 / 2049 (3500HD long bed)
|
Front Track
(in. / mm):
|
68.1 / 1731
|
68.1 / 1731
|
68.1 / 1731
|
Rear Track
(in. / mm):
|
68.3 / 1736 (SRW)
75 / 1905 (DRW)
|
68.3 / 1736 (SRW)
75 / 1905 (DRW)
|
68.3 / 1736 (SRW)
75 / 1905 (DRW)
|
2500HD Ground Clearance (in. / mm):
|
10.19 / 259
|
10.19 / 259 (standard bed)
10.15 / 258 (long bed)
|
10.12 / 257 (standard bed)
10.08 / 256 (long bed)
|
3500HD Ground Clearance (in. / mm):
|
11.82 / 285 (SRW)
10.47 / 266 (DRW)
|
11.18 / 284 (SRW)
10.39 / 264 (DRW)
|
11.18 / 284 (standard bed & SRW)
11.14 / 283 (long bed & SRW)
10.39 / 264 (long bed & DRW)
|
INTERIOR DIMENSIONS
|
Regular Cab
|
Double Cab
|
Crew Cab
|
Headroom
(in. / mm):
|
43.11 / 1095
|
43.03 / 1093 (front)
39.88 / 1013 (rear)
|
43.03 / 1093 (front)
40.12 / 1019 (rear)
|
Legroom
(in. / mm):
|
44.53 / 1131
|
44.53 / 1131 (front)
35.24 / 895 (rear)
|
44.53 / 1131 (front)
43.4 / 1102 (rear)
|
Shoulder Room
(in. / mm):
|
66.06 / 1678
|
66.02 / 1677 (front)
64.88 / 1648 (rear)
|
66.02 / 1677 (front)
65.3 / 1659 (rear)
|
Hip Room
(in. / mm):
|
60.9 / 1547
|
61.18 / 1554 (front)
60.24 / 1530 (rear)
|
61.18 / 1554 (front)
60.24 / 1530 (rear)
|
BASE CURB WEIGHT1
|
Regular Cab
|
Double Cab
|
Crew Cab
|
2500HD – 2WD (lb. / kg):
|
6267 / 2842 – gas
6894 / 3127 – diesel
|
6584 / 2986 – gas (standard bed)
7238 / 3283 – diesel (standard bed)
6718 / 3047 – gas (long bed)
7411 / 3361 – diesel (long bed)
|
6688 / 3033 – gas (standard bed)
7388 / 3351 – diesel (standard bed)
6803 / 3085 – gas (long bed)
7511 / 3407 – diesel (long bed)
|
2500HD – 4WD (lb. / kg):
|
6614 / 3000 – gas
7241 / 3284 – diesel
|
6931 / 3143 – gas (standard bed)
7585 / 3440 – diesel
(standard bed)
7022 / 3185 – gas (long bed)
7715 / 3499 – diesel (long bed)
|
7019 / 3183 – gas (standard bed)
7719 / 3501 – diesel (standard bed)
7111 / 3225 – gas (long bed)
7804 / 3539 – diesel (long bed)
|
3500HD – 2WD SRW (lb. / kg):
|
6404 / 2904 – gas
7053 / 3199 – diesel
|
6862 / 3112 – gas
7578 / 3437 – diesel
|
6832 / 3099 – gas (standard bed)
7555 / 3427 – diesel (standard bed)
6975 / 3163 – gas (long bed)
7711 / 3497 – diesel (long bed)
|
3500HD – 4WD SRW (lb. / kg):
|
6779 / 3075 – gas
7429 / 3369 – diesel
|
7169 / 4362 – gas
7886 / 3124 – diesel
|
7153 / 3244 – gas (standard bed)
7876 / 3572 – diesel (standard bed)
7254 / 3290 – gas (long bed)
7970 / 3615 – diesel (long bed)
|
3500HD – 2WD DRW (lb. / kg):
|
6722 / 3049 – gas
7372 / 3344 – diesel
|
7180 / 3256 – gas
7897 / 3582 – diesel
|
7293 / 3308 – gas (long bed)
8030 / 3642 – diesel (long bed)
|
3500HD – 4WD DRW (lb. / kg):
|
7097 / 3219 – gas
7748 / 3514 – diesel
|
7492 / 3398 – gas
8204 / 3721 – diesel
|
7572 / 3434 – gas (long bed)
8289 / 3759 – diesel (long bed)
|
1With standard 17-inch wheels on 2500HD and 3500HD DRW; standard 18-in. or 20-in. wheels on 3500HD SRW.
BASE GVWR1
|
Regular Cab
|
Double Cab
|
Crew Cab
|
2500HD – 2WD (lb. / kg):
|
10000 / 4536 – gas
10550 / 4785 – diesel
|
10050 / 4559 – gas (standard bed)
10700 / 4854 – diesel (standard bed)
10200 / 4627 – gas (long bed)
10900 / 4944 – diesel (long bed)
|
10150 / 4604 – gas (standard bed)
10800 / 4899 – diesel (standard bed)
10300 / 4672 – gas (long bed)
11000 / 4990 – diesel (long bed)
|
2500HD – 4WD (lb. / kg):
|
10250 / 4649 – gas
10900 / 4944 – diesel
|
10350 / 4695 – gas (standard bed)
11000 / 4990 – diesel (standard bed)
10500 / 4763 – gas (long bed)
11200 / 5080 – diesel (long bed)
|
10450 / 4750 – gas (standard bed)
11150 / 5058 – diesel (standard bed)
10650 / 4831 – gas (long bed)
11350 / 5158 – diesel (long bed)
|
3500HD – 2WD SRW (lb. / kg):
|
10950 / 4966 – gas
11500 / 5216 – diesel
|
11300 / 5125 – gas
11850 / 5375 – diesel
|
11200 / 5080 – gas (standard bed)
11750 / 5330 – diesel (standard bed)
11350 / 5148 – gas (long bed)
11900 / 5398 – diesel (long bed)
|
3500HD – 4WD SRW (lb. / kg):
|
11300 / 5125 – gas
11800 / 5352 – diesel
|
11600 / 5261 – gas
12150 / 5511– diesel
|
11550 / 5238 – gas (standard bed)
12100 / 5489 – diesel (standard bed)
11700 / 5307 – gas (long bed)
12250 / 5557 – diesel (long bed)
|
3500HD – 2WD DRW (lb. / kg):
|
14000 / 6350 – gas
14000 / 6350 – diesel
|
14000 / 6350 – gas
14000 / 6350 – diesel
|
14000 / 6350 – gas
14000 / 6350 – diesel
|
3500HD – 4WD DRW (lb. / kg):
|
14000 / 6350 – gas
14000 / 6350 – diesel
|
14000 / 6350 – gas
14000 / 6350 – diesel
|
14000 / 6350 – gas
14000 / 6350 – diesel
|
1When properly equipped; includes weight of vehicle, passengers, cargo and equipment. Specifications include standard 17-inch wheels on 2500HD and 3500HD DRW; standard 18-in. or 20-in. wheels on 3500HD SRW.
BASE PAYLOAD1
|
Regular Cab
|
Double Cab
|
Crew Cab
|
2500HD – 2WD (lb. / kg):
|
3689 / 1673 – gas
3613 / 1638 – diesel
|
3422 / 1552 – gas (standard bed)
3418 / 1550 – diesel (standard bed)
3438 / 1559 – gas (long bed)
3445 / 1562 – diesel (long bed)
|
3418 / 1550 – gas (standard bed)
3368 / 1527 – diesel (standard bed)
3453 / 1566 – gas (long bed)
3445 / 1562 – diesel (long bed)
|
2500HD – 4WD (lb. / kg):
|
3592 / 1629 – gas
3615 / 1639 – diesel
|
3375 / 1530 – gas (standard bed)
3372 / 1529 – diesel (standard bed)
3434 / 1557 – gas (long bed)
3441 / 1560 – diesel (long bed)
|
3387 / 1536 – gas (standard bed)
3387 / 1536 – diesel (standard bed)
3495 / 1585 – gas (long bed)
3508 / 1591 – diesel (long bed)
|
3500HD – 2WD SRW (lb. / kg):
|
4502 / 2042 – gas
4403 / 1997 – diesel
|
4394 / 1993 – gas
4228 / 1917 – diesel
|
4324 / 1969 – gas (standard bed)
4151 / 1882 – diesel (standard bed)
4331 / 1964 – gas (long bed)
4145 / 1880 – diesel (long bed)
|
3500HD – 4WD SRW (lb. / kg):
|
4477 / 2030 – gas
4327 / 3281 – diesel
|
4387 / 1990 – gas
4220 / 1914 – diesel
|
4353 / 1974 – gas (standard bed)
4180 / 1896 – diesel (standard bed)
4402 / 1996 – gas (long bed)
4236 / 1921 – diesel (long bed)
|
3500HD – 2WD DRW (lb. / kg):
|
7234 / 3281 – gas
6638 / 3010 – diesel
|
6776 / 3073 – gas
6059 / 2748 – diesel
|
6663 / 3022 – gas
5926 / 2687 – diesel
|
3500HD – 4WD DRW (lb. / kg):
|
6859 / 3111 – gas
6209 / 2816 – diesel
|
6464 / 2932 – gas
5752 / 2609 – diesel
|
6384 / 2895 – gas
5667 / 2570 – diesel
|
1For comparison purposes only. See the owner's manual and the label on the vehicle door jamb for the carrying capacity of a specific vehicle.
MAX TRAILERING1 – CONVENTIONAL
|
Regular Cab
|
Double Cab
|
Crew Cab
|
2500HD – 2WD (lb. / kg):
|
14500 / 6577 – gas
14500 / 6577 – diesel
|
14500 / 6577 – gas (standard bed)
14500 / 6577 – diesel (standard bed)
16000 / 7257 – gas (long bed)
17900 / 8119 – diesel (long bed)
|
16000 / 7257 – gas (standard bed)
20000 / 9072 – diesel (standard bed with NHT pkg.)
16000 / 7257 – gas (long bed)
20000 / 9072 – diesel (long bed with NHT pkg.)
|
2500HD – 4WD (lb. / kg):
|
14500 / 6577 – gas
14500 / 6577 – diesel
|
14500 / 6577 – gas (standard bed)
14500 / 6577 – diesel (standard bed)
16000 / 7257 – gas (long bed)
17600 / 7983 – diesel (long bed)
|
16000 / 7257 – gas (standard bed)
20000 / 9072 – diesel (standard bed with NHT pkg.)
16000 / 7257 – gas (long bed)
20000 / 9072 – diesel (long bed with NHT pkg.)
|
3500HD – 2WD SRW
(lb. / kg):
|
14500 / 6577 – gas
14500 / 6577 – diesel
|
16000 / 7257 – gas
20000 / 9072 – diesel
|
16000 / 7257 – gas (standard bed)
20000 / 9072 – diesel (standard bed)
16000 / 7257 – gas (long bed)
20000 / 9072 – diesel (long bed)
|
3500HD – 4WD SRW
(lb. / kg):
|
14500 / 6577 – gas
14500 / 6577 – diesel
|
16000 / 7257 – gas
20000 / 9072 – diesel
|
16000 / 7257 – gas (standard bed)
20000 / 9072 – diesel (standard bed)
16000 / 7257 – gas (long bed)
20000 / 9072 – diesel (long bed)
|
3500HD – 2WD DRW
(lb. / kg):
|
18700 / 8482 – gas
20000 / 9072 – diesel
|
18300 / 8300 – gas
20000 / 9072 – diesel
|
18200 / 8255 – gas
20000 / 9072 – diesel
|
3500HD – 4WD DRW
(lb. / kg):
|
18400 / 8346 – gas
20000 / 9072 – diesel
|
18000 / 8164 – gas
20000 / 9072 – diesel
|
17800 / 8074 – gas
20000 / 9072 – diesel
|
1Before you buy a vehicle or use it for trailering, carefully review the Trailering section of the Owner’s Manual.
MAX TRAILERING1 – 5TH WHEEL/GOOSENECK
|
Regular Cab
|
Double Cab
|
Crew Cab
|
2500HD – 2WD (lb. / kg):
|
18700 / 8482 – gas
22430 / 10174 – diesel (with NHT pkg.)
|
18500 / 8392 – gas (standard bed)
18200 / 8255 – diesel (standard bed)
18400 / 8346 – gas (long bed)
18000 / 8164 – diesel (long bed)
|
18500 / 8392 – gas (standard bed)
21510 / 9756 – diesel (standard bed with NHT pkg.)
18500 / 8392 – gas (long bed)
22070 / 10010 – diesel (long bed with NHT pkg.)
|
2500HD – 4WD (lb. / kg):
|
18300 / 8300 – gas
22050 / 10001 – diesel (with NHT pkg.)
|
18200 / 8255 – gas (standard bed)
17900 / 8119 – diesel (standard bed)
18000 / 8164 – gas (long bed)
17700 / 8028 – diesel (long bed)
|
18400 / 8346 – gas (standard bed)
21600 / 9797 – diesel (standard bed with NHT pkg.)
18370 / 8332 – gas (long bed)
21510 / 9756 – diesel (long bed with NHT pkg.)
|
3500HD – 2WD SRW
(lb. / kg):
|
19080 / 8654 – gas
22430 / 10174 – diesel
|
18620 / 8446 – gas
21900 / 9933 – diesel
|
18650 / 8459 – gas (standard bed)
21900 / 9797 – diesel (standard bed)
18510 / 8396 – gas (long bed)
22070 / 10010 – diesel (long bed)
|
3500HD – 4WD SRW
(lb. / kg):
|
18700 / 8482 – gas
22050 / 10001 – diesel
|
18310 / 8305 – gas
21590 / 9793 – diesel
|
18300 / 8300 – gas (standard bed)
21600 / 9797– diesel (standard bed)
18230 / 8269 – gas (long bed)
21510 / 9756 – diesel (long bed)
|
3500HD – 2WD DRW
(lb. / kg):
|
18760 / 8509 – gas
36000 / 16329 – diesel (with NHT pkg.)2
|
18300 / 8300 – gas
31580 / 14324 – diesel
|
18240 / 8273 – gas
31450 / 14265 – diesel
|
3500HD – 4WD DRW
(lb. / kg):
|
18380 / 8337 – gas
31500 / 14288 – diesel
|
17990 / 8160 – gas
31280 / 14188 – diesel
|
17800 / 8074 – gas 31000 / 14061 – diesel
|
1Before you buy a vehicle or use it for trailering, carefully review the Trailering section of the Owner’s Manual.
2When equipped with gooseneck hitch. Trailering rating is 32,000 lbs. / 14,515 kg with fifth-wheel hitch.
NOTE: All towing capabilities measured using SAE J2807 metrics.
